4l85e Transmission

4L80-E/4L85-E
Overview
Manufacturer	General Motors
Production	1991–2013
Body and chassis
Class	4-speed longitudinalautomatic transmission
Chronology
Predecessor	Turbo-Hydramatic 3L80
Successor	6L80/6L90

4l85e Transmission Vs 4l80e
4l85e Transmission Controller
4l85e Transmission For Sale
4l85e Transmission Fluid

The 4L80-E (and similar 4L85-E) was a series of heavy-duty automatic transmissions from General Motors designed for longitudinal engine configurations. The 4L80-E was heavily based on the Turbo-Hydramatic 400 first produced in October 1963, adding electronic controls and an overdriven fourth gear. 4L80-Es were optioned only in Chevrolet/GMC pickups, Suburban 2500s, vans, and commercial vehicles, and the Hummer H1. It was also adopted by Rolls-Royce in 1991 and modified after extensive testing,^[1] and used initially in the Bentley Continental R, and subsequently other Rolls-Royce and Bentley vehicles. The 4L80E and 4L85E were built at Willow Run Transmission in Ypsilanti, Michigan.

4L85E Transmission For Sale The 4L85E was introduced in 2002 as a more heavy duty version of the 4L80E. It included a 5-pinion reaction gear-set and was designed for Jeeps, SUV's and trucks up to 16,500 lbs. Gross vehicle weight rating with engines up to 460 foot pounds. Of torque and with a towing capacity up to 22,000 LBS. 4L85E – Level 4 Transmission with Torque Converter. Email this page to a friend. Horse Power: 1200 (Up to 1000 ft-lbs Torque) Converter: Custom Built & Custom. The SuperMatic 4L85-E Includes additional clutch plates allowing you to add up to 690 lb.-ft. Does not include torque converter.

Gear ratios:

1	2	3	4	R
2.48	1.48	1.00	0.75	2.07

4L80-E[edit]

A Hydra-Matic 4L80 transmission at the Ypsilanti Automotive Heritage Museum

The 4L80-E (RPO MT1) is rated to handle engines with up to 440 ft·lbf (597 N·m) of torque.^[2] The 4L80-E is rated to max GVWR of 18,000 (Axle and vehicle dependent)^[3]

The 4L80-E uses 2 shift solenoids, initially called Shift Solenoid A & Shift Solenoid B, later changed to comply with OBD II (On Board Diagnostics revision 2) regulations to 1-2 Shift Solenoid & 2-3 Shift solenoid. By activating and deactivating the solenoids in a predetermined pattern by the PCM, 4 distinct gear ratios can be achieved. The shift solenoid pattern, also sometimes referred to as solenoid firing order, is as follows;

Shift Solenoid Pattern[edit]

1-2 Solenoid	2-3 Solenoid
1st Gear	On	Off
2nd Gear	Off	Off
3rd Gear	Off	On
4th Gear	On	On

No power results in 2nd Gear as 'Limp home mode'.

Applications[edit]

1991–2013 Chevrolet C/K/Chevrolet Silverado/GMC Sierra 2500 & 3500
1991–2013 Chevrolet/GMC Suburban/GMC Yukon XL 2500 & 3500
1991–2009 Chevrolet Van/Chevrolet Express/GMC Savana 2500 & 3500
2002–2006 Chevrolet Avalanche 2500 General Motors LS with L18 V8 only
1992-2006 Hummer H1
1992–1998 Rolls-Royce Silver Spirit/Spur II, III, IV
1991–1992 Bentley Eight
1991–1997 Bentley Turbo R
1991–2002 Bentley Continental R/S/T
1999–2006 Bentley Arnage Red Label / Bentley Arnage R/RL/T
1993–1996 Jaguar XJS
1994–1997 Jaguar XJR
1993–1997 Jaguar XJ12 / Daimler Double Six
1996–1999 Aston Martin DB7
2000-2006 Chevrolet HD trucks with L18 V8

4L85-E[edit]

The 4L85-E (RPO MN8) is rated to handle vehicles with up to 690 ft·lbf (935 N·m) of torque.^[4] The 4L85E is rated to handle vehicles with a GVWR of up to 18,000 lbs (dependent on axle ratio and vehicle)^[5]

Applications:

Chevrolet Avalanche8.1 Vortec only.
Chevrolet Suburban 8.1 Vortec only.
GMC Yukon XL 8.1 Vortec only.
Chevrolet Express with Duramax Diesel or 8.1 Vortec 2500 & 3500 only.
GMC Savana with Duramax Diesel or 8.1 Vortec only.

References[edit]

^Adcock, Ian (1992). Bentley Continental R. London: Osprey Publishing. p. 113. ISBN185532 260 9.
^'Archived copy'. Archived from the original on 2013-12-22. Retrieved December 22, 2013.CS1 maint: discouraged parameter (link) CS1 maint: archived copy as title (link)
^GM Powertrain. '07 Hydramatic 4L series'. General Motors. Retrieved January 5, 2014.CS1 maint: discouraged parameter (link)
^https://www.chevrolet.com/performance/transmissions/supermatic-4l85-e
^GM powertrain. '07 Hydramatic 4L Series Specs'. General Motors. Retrieved January 5, 2014.CS1 maint: discouraged parameter (link)

Retrieved from 'https://en.wikipedia.org/w/index.php?title=GM_4L80-E_transmission&oldid=1005272686'

4L85E - To 800 HP

4L85E - To 800 HP

$5,500.00

4L85E

250.00 LBS

Calculated at checkout

Product Description

4L85E Level 1

SuperMatic 4L85-E 4-Speed Transmission

Newly designed for use on our ZZ572/720 crate engine

All new parts, including additional clutch plates

Improved valve body for firmer shifts

Direct bolt-on for Gen 1 small block and all big blocks

Gear ratios: 1st: 2.48, 2nd: 1.48, 3rd: 1.00, 4th: 0.75
